How to set the style for line drawing using imagesetstyle() function in PHP?

The imagesetstyle() function is an inbuilt PHP function used to set custom styles for line drawing. It works with all line drawing functions like imagepolygon() and imageline() to create dashed, dotted, or patterned lines.

Syntax

bool imagesetstyle(resource $image, array $style)

Parameters

imagesetstyle() takes two parameters −

• $image − The image resource to work on, created by functions like imagecreate() or imagecreatetruecolor().

• $style − An array of pixel colors that defines the line pattern. Each element represents one pixel in the repeating pattern.

Return Value

Returns True on success or False on failure.

Example 1: Creating Dashed Lines

This example demonstrates creating a simple dashed line pattern ?

<?php
    header("Content-type: image/jpeg");
    $img = imagecreatetruecolor(700, 300);
    $white = imagecolorallocate($img, 255, 255, 255);
    $red = imagecolorallocate($img, 255, 0, 0);

    // Fill background with white
    imagefill($img, 0, 0, $white);

    // Create dashed line: 5 red pixels, 5 white pixels
    $style = array($red, $red, $red, $red, $red, $white, $white, $white, $white, $white);
    imagesetstyle($img, $style);
    imageline($img, 50, 100, 650, 100, IMG_COLOR_STYLED);

    imagejpeg($img);
    imagedestroy($img);
?>

Example 2: Complex Pattern with Brush

This example shows combining imagesetstyle() with imagesetbrush() for advanced patterns ?

<?php
    header("Content-type: image/png");
    $img = imagecreatetruecolor(400, 200);
    $white = imagecolorallocate($img, 255, 255, 255);
    $blue = imagecolorallocate($img, 0, 0, 255);
    $green = imagecolorallocate($img, 0, 255, 0);

    // Fill background
    imagefill($img, 0, 0, $white);

    // Create alternating blue-green pattern
    $style = array($blue, $blue, $green, $green, $white, $white);
    imagesetstyle($img, $style);

    // Draw multiple styled lines
    imageline($img, 10, 50, 390, 50, IMG_COLOR_STYLED);
    imageline($img, 10, 100, 390, 100, IMG_COLOR_STYLED);
    imageline($img, 10, 150, 390, 150, IMG_COLOR_STYLED);

    imagepng($img);
    imagedestroy($img);
?>

Key Points

• The $style array defines a repeating pattern for the line.

• Use IMG_COLOR_STYLED as the color parameter in drawing functions to apply the style.

• Combine with IMG_COLOR_STYLEDBRUSHED when using custom brushes.

• Transparent pixels can be used in the pattern for gaps.

Conclusion

The imagesetstyle() function provides powerful control over line appearance in PHP image manipulation. By defining custom pixel patterns, you can create professional−looking dashed, dotted, or complex styled lines for graphics and diagrams.
