How to create a Box to display components from left to right in Java

Box is lightweight container that uses a BoxLayout object as its layout manager. To display components from left to right, use Box createHorizontalBox() method.

Let us first create some button components −

JButton button1 = new JButton("One");
JButton button2 = new JButton("Two");
JButton button3 = new JButton("Three");
JButton button4 = new JButton("Four");
JButton button5 = new JButton("Five");
JButton button6 = new JButton("Six");

Now, crate a Box and align all the buttons from left to right −

Box box = Box.createHorizontalBox();
box.add(button1);
box.add(button2);
box.add(button3);
box.add(button4);
box.add(button5);
box.add(button6);

The following is an example to create a Box to display components from left to right −

Example

package my;
import java.awt.BorderLayout;
import javax.swing.Box;
import javax.swing.JButton;
import javax.swing.JFrame;
import javax.swing.JScrollPane;
public class SwingDemo {
   public static void main(String args[]) {
      JFrame frame = new JFrame("Demo");
      frame.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
      JButton button1 = new JButton("One");
      JButton button2 = new JButton("Two");
      JButton button3 = new JButton("Three");
      JButton button4 = new JButton("Four");
      JButton button5 = new JButton("Five");
      JButton button6 = new JButton("Six");
      Box box = Box.createHorizontalBox();
      box.add(button1);
      box.add(button2);
      box.add(button3);
      box.add(button4);
      box.add(button5);
      box.add(button6);
      JScrollPane jScrollPane = new JScrollPane();
      jScrollPane.setViewportView(box);
      frame.add(jScrollPane, BorderLayout.CENTER);
      frame.setSize(550, 250);
      frame.setVisible(true);
   }
}

This will produce the following output −
